بررسی تخصصی
کالیبراتور برنامهپذیر GS610 ساخت YOKOGAWA ژاپن
Yokogawa GS610 یک منبع تغذیه و بار الکترونیکی برنامهپذیر (Precision Source/Measure Unit SMU) با دقت بالا است که برای تست و اندازهگیری جریان و ولتاژ در آزمایشگاههای الکترونیک و صنایع مختلف طراحی شده است. این دستگاه میتواند بهعنوان منبع ولتاژ، منبع جریان و بار الکترونیکی عمل کند و برای کالیبراسیون، تست قطعات نیمههادی و تجهیزات الکترونیکی استفاده میشود.
ویژگیهای کلیدی Yokogawa GS610
✅ حالتهای عملکردی:
🔹 منبع ولتاژ (Voltage Source): خروجی ولتاژ 0V تا ±110V
🔹 منبع جریان (Current Source): خروجی جریان 0A تا ±3.2A
🔹 بار الکترونیکی (Electronic Load): امکان جذب جریان از منابع خارجی
✅ محدودههای اندازهگیری دقیق:
🔹 ولتاژ: از 10μV تا 110V
🔹 جریان: از 10pA تا 3.2A
🔹 دقت بالا: 6.5 رقم برای اندازهگیری ولتاژ و جریان
✅ ویژگیهای دیجیتایزر (Data Logging & Digitizer):
🔹 نرخ نمونهبرداری تا 100kS/s (100 هزار نمونه در ثانیه)
🔹 امکان ثبت و تحلیل سیگنالهای گذرا و تغییرات دینامیکی
✅ اتصالات و کنترل از راه دور:
🔹 پورتهای ارتباطی: USB، GPIB، و Ethernet برای اتوماسیون و کنترل از راه دور
🔹 پشتیبانی از SCPI برای اجرای دستورات کنترلی
✅ قابلیتهای پیشرفته:
🔹 شبیهسازی منابع واقعی برای تست عملکرد تجهیزات در شرایط مختلف
🔹 حالت پالس (Pulse Mode) برای تست قطعات حساس به دما
🔹 نمایشگر LCD گرافیکی برای مشاهده دادهها و تنظیمات
کاربردهای Yokogawa GS610
✔ کالیبراسیون دقیق تجهیزات الکترونیکی
✔ تست قطعات نیمههادی و سنسورها
✔ شبیهسازی شرایط واقعی برای تجهیزات برقی و باتریها
✔ تحلیل رفتار قطعات الکترونیکی در برابر تغییرات ولتاژ و جریان
✔ استفاده در صنایع مخابرات، خودرو، و فناوری پزشکی
🔹 اگر نیاز به یک منبع تغذیه و بار الکترونیکی دقیق و برنامهپذیر برای آزمایشگاههای تحقیقاتی و صنعتی دارید، Yokogawa GS610 یکی از بهترین انتخابها است.
This source measurement unit is fully performing to your high capacity needs and includes remote control and easy file operation for ease of use.
- Source and sink operation up to 110 V/3.2 A (four-quadrant operation)
- Basic accuracy: ±0.02% (DC voltage generation)
- Sweep output at up to 100-µ intervals
- Comes with abundant sweep patterns (linear, logarithmic, and arbitrary)
- Stores up to 65535 points of source measure data in the internal memory
- Remote control and FTP using Web server function (Optional)
- Easy file operation with the USB storage function
Voltage/Current Generation and Measurement Range
Four-dimensional operation with source operation (current source) and sink operation (current sink) is possible at up to 110 V, 3.2 A, and 60 W.
The output and measurement resolutions are 5.5 digits.
Voltage generation/measurement range: 200 mV to 110 V
Current generation/measurement range: 20 µA to 3.2 A
Maximum output current:
±3.2 A & (at an output voltage of ±12 V or less)
±2 A (at an output voltage of ±30 V or less)
±1 A (at an output voltage of ±60 V or less)
±0.5 A (at an output voltage of ±110 V or less)
Generation and Measurement Functions
The GS610 is made up of a constant current source, a constant voltage source, a voltmeter, and an ammeter. Each function can be combined into numerous operation modes.
Operation modes:
- Voltage generation/current measurement (VS/IM);
- Voltage generation/voltage measurement (VS/VM);
- Current generation/voltage measurement (IS/VM);
- Current generation/current measurement (IS/IM);
- Voltage generation (VS);
- Current generation (IS);
- Resistance measurement (VS/IM or IS/VM)
