اتنیتور MN510C

معرفی

تضعیف کننده (اتنیتور) در فرکانس DC=500MHz ساخت Anritsu ژاپن

بررسی تخصصی

Name: MN510C

Main frame:

Resistance Attenuator) Build-to order product)

J0025A

W0219CE

Standard accessories

Coaxial Cord (S-5DWP · 5D-2W · S-5DWP), 1 m: 2 pcs

Specifications

Frequency Range

DC to 500 MHz

Connector

N-type, 50Ω unbalanced

Return Loss

≥30 dB (DC to 100 MHz)

≥25 dB (100 MHz to 300 MHz)

≥20 dB (300 MHz to 500 MHz)

Maximum Attenuation 91 dB

Step Dial

10 dB × 8, 1 dB × 10, 0.1 dB × 10

Attenuation Accuracy

Step accuracy:

±0.2 dB (0 to 10 dB, DC to 500 MHz)

±0.3 dB (0 to 91 dB, DC to 300 MHz)

±0.5 dB (0 to 91 dB, 300 MHz to 500 MHz)

Residual loss:

≤0.2 dB (DC to 100 MHz)

≤0.4 dB (100 MHz to 300 MHz)

≤0.5 dB (300 MHz to 500 MHz)

Maximum Input

0.25 W (24 dBm)

Operating

Temperature Range 0° to 45°C

Dimensions and Mass 210 (W) × 95 (H) × 150 (D) mm, ≤3 kg
